Vertical bandsaw blade guards shield the operator’s hands from the moving blade during material feeding, reducing the risk of cuts, lacerations, and amputation while containing metal shavings. Each guard pairs a 1/4" polycarbonate shield for full part visibility with a 30mm T-slot aluminum extrusion that adjusts vertically and horizontally to accommodate varying part shapes and cut heights. Available in two models -  a 7" shield for 15" and larger machines, and a 5" shield for 14" and smaller machines.

Key Features

• Meets OSHA 1910.212 general machine guarding requirements
• 1/4" thick polycarbonate (Lexan) shield - impact-resistant with clear sightlines to the cut
• 30mm industrial aluminum T-slot extrusion allows both vertical and horizontal shield repositioning
• Shield flips 180° upward for unobstructed blade changes, tracking adjustment, and machine access
• Adjustable steel lever repositions the guard between cuts without tools
• Powder-coated OSHA Safety Orange (PPG) extrusion for high visibility at the point of operation
• Two shield sizes: 6" W × 7" H  and 4.5" W × 5" H
• Mounts to the front door with supplied bracket and hardware, or to the upper housing side
• Installation requires only two drilled holes
• Replacement shields stocked in 5", 7", 10", and 12" heights; custom sizes available on request
• Fits floor-model vertical bandsaws 12" and larger (not intended for benchtop machines)
